Metrics metrics and more metrics

Know what your nodes are up to

Metrics metrics and more metrics

March 4, 2020
Tom Taylor
Crux is now XTDB

September 2021 Update: Crux has recently been renamed XTDB. This post still refers to XTDB as "Crux" but is still relevant to the version of XTDB released, as of this writing.

However, a completely updated version of this post can be found at We recommend you look at that instead.

The official home for XTDB is now

In the new 1.7 alpha release of Crux there is a LOT of content. Some bug fixes, some refactoring and some new features, including the addition of metrics!

Metrics give you information on how long your queries are taking, how fast/many documents are being ingested and how large your local store is (amongst other things).

In the first release of this feature we have included metrics for several key components:

  • query engine

  • indexer

  • RocksDB

Dropwizard’s metrics library is used to create a registry that can then be passed around to reporters that expose the inner metrics. Currently we provide 5 components to expose metrics:

We’ve made metrics as easy as possible to add to existing Crux nodes. Below is an example node with a RocksDB backend which displays prometheus metrics to the default port 8080. RocksDB metrics have also been included here with the kv-store item in the topology map.

 {:crux.node/topology ['crux.standalone/topology
  :crux.kv/db-dir "data/db-dir-1"
  :crux.standalone/event-log-kv-store 'crux.kv.rocksdb/kv
  :crux.standalone/event-log-dir "data/eventlog-1"})

Besides pointing at the endpoint in your prometheus config, that’s all that’s required.

prometheus example

In 1.7 we’ve changed the way kv-store is specified. It is now done in the topology map, although the old method of defining it as an argument still works for the moment.

Cloudwatch is just as easy.

  {:crux.node/topology ['crux.standalone/topology
                        ;; this time without RocksDB metrics
   :crux.kv/db-dir "data/db-dir-1"
   :crux.standalone/event-log-kv-store 'crux.kv.rocksdb/kv
   :crux.standalone/event-log-dir "data/eventlog-1"})

When run on ECS the AWS api is able to detect the relevant credentials to upload metrics to cloudwatch. If running locally we also provide options to specify the desired region to upload and also to provide valid credentials.

cloudwatch example

In the most recent Crux showcase I demonstrated this in action working with our new benchmark environment running on AWS (Skip to 11 mins for metrics).

For more configurations and options take a look at the docs.

If you need any more help, give us a shout!
